Analog & Digital

Pressure Gauges & Transmitters

        Lumenite® sanitary analog pressure gauges,digital

pressure gauges / transmitters and sanitary pressure

transmitters conform to 3A standard 37-01.All Lumenite®

sanitary products are TPV (third party verified).

STANDARD SPECIFICATIONS :

• 3A, CEE, TPV third party verified

• TPA terminal point accuracy (no BFSL)

• 5 digit LCD display with .60 inch characters and optional

  back lighting

• 0.25% full scale accuracy

• Optional 4-20mA transmitter output with battery backup

• Replaces both a pressure gauges and 4-20mA pressure

  transmitter

• 316 s.s. sanitary fitting and socket for CIP cleaning

• Percent of range bargraph

• Vacuum through 20,000 psi. ranges

• Alternate metric and English unit of measure,

  programmable through keypad,  include mmHg, in H20,

  mBar, Kpa, kg/cm2, and bar

• Password protected zero, midpoint, and span

• Lower 6’o’clock standard mount

• Operating temperature 14˚F to 140˚F (-10˚C to 60˚C)

Model

LSDPG Sanitary

Digital Pressure

Gauge / Transmitter

STANDARD SPECIFICATIONS :

• Stainless steel welded tube and socket

• 4” standard case size

• ± 1% full scale calibrated accuracy

• 100% helium leak tested

• Electropolished 316 s.s. diaphragm

• Available in 1.5 or 2” Tri-Clamp Connection

• 100% Helium leak tested

• 304 s.s. housing

• Ambient temperature range up to 300˚F standard

• 100% hand calibrated and certified to exceed the current

  ASME B40.1

• 90mm standard case

• Calibrated Accuracy = 1.5% f.s. for ranges 100 p.s.i.

  or more

• All gauges designed for C.I.P.

• Dry gauges suitable for autoclave sterilization

• Designed to withstand 50% overpressure with minimal

  loss of accuracy sanitary pressure analog gauge

Model

LSPG Sanitary

Pressure Gauge

STANDARD SPECIFICATIONS :

• 3A, CEE, TPV third party verified

• TPA terminal point accuracy (no BFSL)

• 5 digit LCD display with .60 inch characters and optional

  back lighting

• 0.25% full scale accuracy

• Optional 4-20mA transmitter output with battery backup

• Replaces both a pressure gauges and 4-20mA pressure

  transmitter

• 316 s.s. sanitary fitting and socket for CIP cleaning

• Percent of range bargraph

• Vacuum through 20,000 psi. ranges

• Alternate metric and English unit of measure,

  programmable through keypad,  include mmHg, in H20,

  mBar, Kpa, kg/cm2, and bar

• Password protected zero, midpoint, and span

• Lower 6’o’clock standard mount

• Operating temperature 14˚F to 140˚F (-10˚C to 60˚C)

Model

LSPT Sanitary

Pressure Transmitter
