Octal Socket type conductivity level switches have a single relay with
one set of dry contacts. These tank level sensors are ideal for single point
on / off switching or filling and emptying operations. The Paneleveline™
series is specifically designed for panel builders and contractors although
it can be mounted in a polycarbonate or 304 s.s. housing and used as a
stand alone control.
Octal Socket Mount Standard Options
SENSITIVITY :
WFLT - standard sensitivity (water, soup, vinegar)
WFMFT - no foam sensitivity (milk, cream, whey)
WFLTV - variable sensitivity (used for a wide range of liquids)
MOUNTING TYPE :
SM - octal socket mount
RELAYS :
201 - single relay operation for single on/off switch or
filling/emptying operation
VOLTAGE :
24 - 24VAC
1 - 110VAC
2 - 220VAC
4 - 440VAC
HOUSING (optional) :
PWP - Nema 4x polycarbonate waterproof, corrosion resistant enclosure
SWP - Nema 4X 304 s.s. waterproof, corrosion resistant enclosure
SAMPLE PART # : WFLT - SM - 2011 - PWP
Octal Socket Mount
