Din-Rail type conductivity level switches have 1, 2, or 3 relay
operation with dry contacts. These tank level sensors are ideal for single
point on/off switching or filling and emptying operations.
The Paneleveline™ series is specifically designed for panel builders and
contractors although it can be mounted in a polycarbonate or 304 s.s.
housing and used as a stand alone control.
Model : 201, 401, 601
Din-Rail Mount Standard Options
SENSITIVITY :
WFLT - standard sensitivity (water, soup, vinegar)
WFMFT - no foam sensitivity (milk, cream, whey)
WFLTV - variable sensitivity (wide range of liquids)
MOUNTING TYPE :
DM - din-rail mount
RELAYS :
• 201 - one relay for 1 single on/off switch or
1 filling / emptying operation
• 401 - two relays for 2 single on / off switches
OR 1 filling / emptying operation with 1 on / off
switch OR 2 filling / emptying operations in
separate tanks
• 601 - three relays for 3 single on / off switches
OR 1 filling / emptying operation with 2 on / off
switches OR 3 filling / emptying operations in
the same or separate tanks
VOLTAGE :
24 - 24VAC
1 - 110VAC
2 - 220VAC
4 - 440VAC
HOUSING (optional) :
PWP - Nema 4x polycarbonate waterproof,
corrosion resistant enclosure
SWP - Nema 4X 304 s.s. waterproof,
corrosion resistant enclosure
SAMPLE PART # : WFLT - SM - 2011 - PWP
Shown : WFLTV-DM-2011
tank level sensor 1 relay
conductivity level control,
din rail mounting, variable
sensitivity (optional) feature
for various liquids, 110VAC
Dimensions :
4-3/4" H, 2-3/4" W, 1-3/4" L
Shown : WFLTV-DM-4011
tank level sensor 2 relay
conductivity level control,
din rail mounting, variable
sensitivity (optional) feature
for various liquids, 110VAC,
equivalent to two 201 series
controls
Dimensions :
4-3/4 H, 2-3/4 W, 2-7/8 L
Shown : WFLTV-DM-6011
tank level sensor 3 relay
conductivity level control,
din rail mounting, variable
sensitivity (optional) feature
for various liquids, 110VAC,
equivalent to three 201 series controls
Dimensions :
4-3/4 H, 2-3/4 W, 3-7/8 L
Din-Rail Mount
